Product Details
Place of Origin: WUXI
Brand Name: Consensic
Certification: PTC23041812701C-CN01
Model Number: CAFS5008
Payment & Shipping Terms
Minimum Order Quantity: Please contact us for details
Price: Offline conversation or face-to-face discussion
Delivery Time: 3-7 work days
Payment Terms: L/C/Ade/Pellet/Texi Union, MoneyGram, Alipay, and business-to-business payments
Supply Ability: 999
Response Time: |
20ms Optional |
Methods Of Communication: |
485/I2C Optional |
Interface: |
G3/8Customizable |
Temperature: |
Medium Temperature (-10~65)°C |
Overall Material: |
Aluminum Alloy (stainless Steel Optional) |
Flow Range: |
20/50/100/200/300slpm Can Be Customized |
Response Time: |
20ms Optional |
Methods Of Communication: |
485/I2C Optional |
Interface: |
G3/8Customizable |
Temperature: |
Medium Temperature (-10~65)°C |
Overall Material: |
Aluminum Alloy (stainless Steel Optional) |
Flow Range: |
20/50/100/200/300slpm Can Be Customized |
High accuracy (1.5% F.S accuracy)
Linear output and no temperature compensation required
Long-term stability with minimal zero drift
Fast response time (65 ms response time)
The flow rate range is 0-60m/s, and the impact resistance is 100g
Solid-state sensing core (no surface voids or fragile membranes) that resists clogging and pressure shocks
Analog output (1 to 5 V) (digital I2C communication output available)
It can be adapted to the measurement of relatively humid gases
Operating temperature: -25°C to 65°C, storage temperature: -40°C to 85°C, humidity: 0 to 100% RH
The sensor is resistant to condensation
Our Medical Flow Sensors are an essential part of any optimized flow measurement system. They are made of high-quality stainless steel, which ensures durability and long-term performance. This material is also resistant to corrosion and other external factors, making it ideal for use in medical facilities.
Our MAFS is a multi-functional sensor that can be used for various applications in medical facilities. The sensor type is specifically designed for medical applications, ensuring accurate and reliable airflow measurement.
The supply voltage of our Medical Flow Sensors is 14, which ensures stable and consistent performance. The working pressure of the sensor is 0.8MPA, making it suitable for use in a wide range of medical applications.
Our Medical Flow Sensors are designed to meet the highest standards of accuracy and reliability, making them the perfect solution for medical facilities. They are easy to install and use, requiring minimal maintenance. With our MAFS, you can be sure that you are getting the best airflow monitoring solution for your medical facility.
|
Functional items |
0.8MPa Medical Flow Sensors 20ms Optional 20 / 50 / 100 / 200 / 300slpm |
||
| Performance parameters | unit | remark | |
| Flow range | 20/50/100/200/300 | slpm | Customizable |
| Power supply | 8~24VDC,50mA | VDC | Optional |
| precision | ±1.5 | % | FS |
| Response time | 20 | ms | Optional |
| Maximum pressure | 0.8 | MPa | Customizable |
| Methods of Communication | 485/I2c | Optional | |
| Output mode | Analog output 1-5V | V | |
| temperature | Medium temperature(-10~65) | ℃ | |
| interface | G3/8 | Customizable | |
| Ingress protection | IP40 | ||
| Calibration method | Air, 0°C, /20°C 101.325kPa | ||
| Overall material | Aluminum alloy (stainless steel optional) | ||
■Industrial■ Medical■ Petroleum■ Gas■ Chemical■ Smelting■ Food Processing■ Instrumentation■ Mechanical and Electrical Equipment
Packing:
The medical flow sensor will be packaged in a sturdy cardboard box to ensure safe transportation.
Shipping:
The product will be shipped via a trusted courier service.
Shipping times may vary depending on the destination, but usually takes 3-7 business days.
Customers will be provided with a tracking number to monitor their shipments.
