Product Details
Place of Origin: WUXI
Brand Name: Consensic
Certification: PTC22072602101C-CN01
Model Number: CAFS6000
Payment & Shipping Terms
Minimum Order Quantity: Please contact us for details
Price: Offline contact or face-to-face discussion can be negotiated
Delivery Time: 3-7 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram/Alipay/business-to-business
Supply Ability: 1000
Maximum Operating Temperature Range: |
-15°C To + 70°C |
Response Time: |
9~500ms Customizable |
Flow Range: |
0~10000sccm Customizable Specifications |
Accuracy: |
2%FS |
Calibration Conditions: |
0℃, 1 Standard Atmosphere |
Maximum Voltage Output: |
4.96 ~5.02V Linear |
Maximum Operating Temperature Range: |
-15°C To + 70°C |
Response Time: |
9~500ms Customizable |
Flow Range: |
0~10000sccm Customizable Specifications |
Accuracy: |
2%FS |
Calibration Conditions: |
0℃, 1 Standard Atmosphere |
Maximum Voltage Output: |
4.96 ~5.02V Linear |
Fit & Install
Ensure that the sensor is undamaged and the wiring is complete.
During installation and connection, ensure that the airflow direction aligns with the sensor's airflow indication direction, and connect the sensor lead line correctly based on the definition.
After confirming the correct connection, proceed to connect the power supply to initiate operation.
For optimal accuracy, it is recommended to preheat the sensor for 2 minutes before use by connecting it to the power supply.
Performance Metrics
Test conditions: Vin = 12±0.1VDC, Ta=25°C. Relative humidity: 40% <relative humidity <60%.
Maximum operating temperature range: -15°C to +70°C Specifications: CAFS6000 Series Least Value | Normal Value | Crest Value | Unit | Remarks Flow Range | 0 | 10000 | sccm | Customizable specifications Service Voltage | 8-24V | V | Customizable Current | 50 | mA Maximum Voltage Output | 4.96 | 5 | 5.02 | V | Linear Zero Point Voltage Output | 0.98 | 1 | 1.02 | V | Linear Accuracy | 1.5 | 2 | %FS Repetitiveness | ±0.3 | %
Resolution Ratio | 0.1 | % gamut Withstand Voltage | 0.3 | 0.5 | MPa | Customizable Response Time | 9 | 65 | 500 | ms | Customizable Zero Drift | 0.2 | %Year gamut Calibration Conditions | 0℃, 1 standard atmosphere Overall Material | Silicon carbide, epoxy resin, PPS, and silicon are used as sealing materials.
Maximum Rating
￭ Operating temperature: -15°C to 70°C
￭ Storage temperature: -25°C to 85°C
￭ Humidity: 0100% RH *
￭ 100 g
￭ The sensor is resistant to condensate water
